Power supply unit Zalman ZM500-LX3 Decamax, 500W, 80 Plus, Power Supply, Black

Power supply unit Zalman ZM500-LX3 Decamax, 500W, 80 Plus, Power Supply, Black. Product specifications are listed below.

Key specifications

• Brand: Zalman
• Model: ZM500-LX3
• Product type: power supply unit
• Type: For PC
• Power: 500 W
• Form factor: ATX
• PFC Type: Active
• Fan diameter: 120 mm
• Standard: ATX 12V in. 2.31
• Overvoltage protection
• Short circuit protection
• Efficiency: 85% (at 230 V AC, typical load)
• Input voltage: 200 V - 240 V
• Frequency: 50 Hz - 60 Hz
• maximum load
• +5VSB - 3.0A
• -12V - 0.3A
• +3.3V - 18A
• +5V - 18A
• +12B - 38A
• Combined load: 100 W 456 W 3.6 W 15 W
• Average working time: 100 thousand hours
• power connectors
• SATA: 4 pcs
• Molex (IDE): 3 pcs
• wire length
• MB 550 mm ± 20 mm
• SATA 450 mm ± 20 mm
• PCI-E 500 mm (6+2) ±20 mm
• additionally
• security
• OPP (overload protection)
• OVP (over voltage)
• SCP (Short Circuit Protection)
• UVP (low voltage protection)
• CE certificates
• CB
• RCM
• EAC
• KC
• RoHS
• Dimensions (HxWxD): 86 x 150 x 140 mm
• Weight: 1.35 kg
• Color: Black
